Titanium powder sintered filter element
Titanium powder sintered filter element
Titanium powder sintered filter element (tube type, plate type) is made of industrial high-purity titanium powder (99.4%) as raw material, after screening, cold isostatic pressing, high temperature and vacuum sintering. Titanium powder filter element has unique excellent performance due to its high-tech material composition and special molding process. Titanium powder filter element made of irregular powder of high-purity titanium or titanium alloy is mainly used in separation and filtration in petrochemical, liquid medicine manufacturing, water treatment and other industries.
Technical parameters
Filtering accuracy | 0.2--100um |
diameter | 30mm, 50mm, 60mm, 70mm, etc. |
Interface form | Flat type, socket type (222 type, 226 type), thread M20/M30/M42/M48 (can be customized) |
Note: The above parameters can be optimized and customized according to working conditions.
Product Features and Benefits
No particles falling off, no pollution of the drug solution, in line with food hygiene and pharmaceutical GMP requirements.
High temperature resistance (300 ℃ wet state), generally can be used below 280 ° normal.
Low differential pressure, small footprint, large flow rate, 0.2 MPa can reach the maximum flow rate.
Good mechanical properties, can be pressed and pumped, easy to operate.
Mechanical strength, high precision, good molding process, the overall length of the non-welded up to 1000 mm.
Good chemical stability, acid resistance, alkali resistance, can be used in a wide range of PH value, strong oxidation resistance, suitable for a variety of environments.
Uniform structure, narrow pore size distribution, high separation efficiency
High pore size filtration, low filtration resistance, high permeability efficiency.
Strong anti-microbial ability, does not interact with microorganisms, and can be used in bioengineering and medical fields.
Renewable, easy to clean, long service life, generally several times the ordinary membrane cartridge, normal use of more than two years.
Product application industry
Decarburization filtration in the process of concentrated preparation of I.V. solution, small injection, eye drops, oral solution and security filtration before terminal filtration in the process of diluted preparation in the pharmaceutical industry.
Impurity removal filtration, decarburization filtration and fine filtration of materials in the production process of raw material plants.
Security filtration of ultrafiltration, RO, EDI system, filtration after ozone sterilization and ozone aeration in water treatment industry.
Clarification and filtration of beverage, liquor, beer, vegetable oil, mineral water, soy sauce and vinegar in food and beverage industry.
Decarburization filtration and precision filtration of liquid products, liquid raw materials, pharmaceutical intermediates in chemical industry, filtration and recovery of ultra-fine crystals and catalysts, precision filtration after resin adsorption and filtration after systematic heat-conducting oil and material removal, and purification of catalytic gases.
Oilfield water filtration and security filtration before reverse osmosis in the field of seawater desalination.
High-temperature decarburization and desiccant filtration in fuel industry.
Steam, compressed air and catalyst filtration in gas purification.
How do we produce your sintered filters and perform quality control?
raw material
LianDaFiltration always insists on selecting uniform raw material powder to produce each sintered filter with large pore size, high tensile strength and temperature stability in the future.
powder filling
The isostatic pressing filling process is used to achieve uniform powder density and eliminate pore defects.
High sinterability
High temperature sintering under vacuum argon protection improves the tightness of micropore connection and enhances pressure resistance.
CNC machining
Through CNC turning and grinding, the filter element geometric accuracy is maintained at ±0.02 mm to meet high-precision filtration requirements.
weld
The laser welded joints are delicate and smooth, with no risk of leakage, which improves the sealing reliability of the filter.
Dimensions
LianDaFiltrationCheck all dimensions of the sintered filter using pressure gauges and high-efficiency dimension monitoring equipment.
filter test
Micropore interception rate evaluation and pressure burst test are used to ensure that each filter element passes the quality inspection in one go.
Product packaging
LianDaFiltration All sintered filter products and accessories are packed in accordance with international standard safety procedures to meet the standards,
Through the above eight processes and strict testing, LiandaFiltration provides you with stable and reliable sintered filter products.
FAQ
High levels of suspended solids or viscous media can accumulate in the pores. We recommend using a pre-filter or reducing inlet concentration.
We recommend online high-pressure backwashing (3–5 bar) or chemical cleaning (alkaline or acid wash). Avoid ultrasonic cleaning, as it can damage the microstructure.
Titanium itself is highly corrosion-resistant, but surface deposits can build up. Regular cleaning and periodic passivation will help maintain performance.
Titanium cartridges are lighter and more corrosion-resistant than stainless steel but come at a higher cost. They’re ideal for highly corrosive or high-temperature applications.
Make sure O-rings or gaskets are clean and undamaged, apply even torque, and avoid metal-to-metal contact that could scratch the cartridge surface.
